Indoor Full Color RGB SMD LED Display Screen Sign for Advertising
Shenzhen Liked Development Co., Ltd- Tube Chip Color：Full Color
- IP Rating：IP65
- Pixel Pitch：3.33mm
- Pixel Configuration：1R, 1G, 1B
- Display Function：Video Display, Image & Text Display, Text Display, Market Display
- Average Power Consumption：300W , m²
Base Info
- Pixel Density：90000DOT,M2
- Scanning Mode：1,12 Scan
- Display Type：LED Video Display
- Application：Advertising
- Certification：CE, RoHS, CCC, ISO9001,EMC
- LED Lamp：Nationstar SMD1921
- Driver IC：Mbi5124
- Bightness CD/Sqm：6000CD,M2
- Grey Scale：65536 Degree
- Life Time：More 100, 000 Hours (80%)
- Mtbf：More 50, 000 Hours
- Operating Temperature：-30~-60t
- Humidity：10%-95%
- Color Temperature：6500-9500K
- Cabinet Size：960*960mm
- Transport Package：Wooden Case Flight Case and Carton
- Specification：320*160mm
- Trademark：hongking
- Origin：China
- HS Code：8528591090
- Production Capacity：5000 Sqm,Year
Description
Technical SpecificationsNO Product name outdoor SMD P3.33 led display 1 Pixel Pitch(mm) 3.33mm 2 Pixel configuration 1R1G1B/ SMD1921 3 Pixel density 90000dots/m2 4 Brightness 6000cd/m2 5 Module size(W*H) 320*160mm 6 Module Resolution (W*H) 96 dots x 48dots 7 Module weight 550g 8 Cabinet size (W*H) 960mm×960mm 9 Drive IC MBI5124 10 Drive mode 1/12 scan 11 Viewing Angle(V/H) 110ºC 12 Grey Scale 65536 degree 13 Life time >100,000 Hours (50%) 14 MTBF >50,000 Hours 15 Operating Voltage AC110V/220V±10% 17 Screen Power Consumption Max: 900w/m2; Average:300w/m2 18 Input Power Frequency 50/60Hz 19 Operating temperature -30--60ºC 20 Humidity 10%-95% 21 Refresh Rate ≥1200HZ 22 Control Method Synchronized with computer monitor 23 Color Temperature 6500K-9500K 24 LED control system LINSN,Nova-star,Colorlight is selectable 25 Control Distance 100 m (no repeating); Optical fiber transmission: 500m- 15km 26 Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI 27 Systems Operating Platform Windows Xp / Windows 7 / windows 8 /8.1 / windows 10
Company descripition:
HONGKINGLED is a publicly listed LED display manufacturer. Our facilities cover an area of 1000 square meters. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 6 years, we have made steady progress.Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. HONGKINGLED products are approved by CE, CCC, EMC and FC. We are fully certified by ISO standards.
