Zipper Blowing Machine/Zipper Blown Machine /Zipper Extruder
Classic Hardware Co., LtdBase Info
Description
Basic Info.
Model NO. ZIP 55/65 Machine Weight 4T Certification CE, ISO9001:2008 Transport Package Stretch Film Package Specification CE/ISO9001 Trademark Changyin Origin China HS Code 84773000 Production Capacity 100sets/YearProduct Description
Based on the film blowing machine ,our zipper blowing machine is designed creatively.With an embossing button auotmatic sealing zip at the very opening ,a bag can be produced automaticlly freely .The main processor adpots frequency conversion speed governing ,photoelectric control ,air filling automatically ,with a high content of science nd technology and power applicability .
We use low LDPE as our raw material and our products can be used to package food ,fruit ,medicine,documents ,industrial products ,clothing and so on .
| Model | ZIP 55 | ZIP 65 |
| Raw material | LDPE | LDPE |
| Width of bag | 50-450mm | 200-550mm |
| Thickness of bag | 0.03-0.10mm | 0.03-0.15mm |
| Diameter of screw | 55mm | 65mm |
| L/D | 28:1 | 28:1 |
| Power of main motor | 5.5kw | 7.5kw |
| Power of Auxiliary machine | 0.75kw | 1.1kw |
| Heater | 12kw | 15kw |
| Cooling | 1.5kw | 2.2kw |
| Power | 25kw | 28kw |
| Voltage | 380v,50hz,3p | 380v,50hz,3p |
| Output | 5-30kg/hr | 6-35kg/hr |
| Mould head | 70,80,100,130,160,180, 200,230,270,300,350,450 | 70,80,100,130,160,180, 200,230,270,300,350,450 |
| Dimension (LXWXH) | 6000*1600*4500 | 6000*1600*4500 |
| Total weight | 1.5T | 1.5T |
