2022 Hot Sale China Cheap Xy-400f Core Drilling Hydraulic Machine
Bestsub Technologies Co., LimitedBase Info
Description
1. Main ParametersMax. Drilling Depth 400m Diameter of drill pipe Φ42,Φ50,Φ60,Φ76 Angle of vertical spindle 0°~90° Drilling capability Φ75mm drill diameter Max. Depth 400m Φ108mm drill diameter Max. Depth 320m Φ127mm drill diameter Max. Depth 280m Φ168mm drill diameter Max. Depth 220m Φ219mm drill diameter Max. Depth 160m Φ273mm drill diameter Max. Depth 130m Φ400mm drill diameter Max. Depth 100m Φ500mm drill diameter Max. Depth 50m Φ600mm drill diameter Max. Depth 30m 2. Vertical Spindle Rotation speed Forward 8 grades 50-1150r/min Reverse 2 grades 29-137r/min Spindle stroke 600mm Spindle bore 62mm Hoisting capability 6000kg Max. Torque 2800N.m 3. Main hoist Lifting speed of single wire 0.5-1.9m/s Diameter of wire rope 14.0mm Carry capacity of single wire 4000kg Diameter of winding drum 300mm Volume of winding drum 50m Lifting capability of single wire 3000kg 4.Auxiliary Hoist Winding drum 140mm Diameter of steel wire rope 6mm Volume of winding drum 450m 5. Mud pump(as per your choice) Horizontal triplex mud pump BW-200II Displacement 200L/min Working pressure 50kg/cm² @ 5MPa Diameter of water inlet hose 65mm Diameter of water outlet hose 38mm 6.Power supply(choose one between the following two) Diesel engine 17.6kw (24HP) Electrical motor Y160L-4,18.5kw 7. Weight and Dimension of main drilling rig Weight 3000kg Dimension 3980×1950×2750mm 8.Six-wheel Trailer Walking speed Less than 10Km/h Frame carrying capacity 8.5 tons Steering wheel 600-14(Single wheel) 0.68 tons Bearing wheel 650-14(double wheels) 0.9 tons Minimum turing angle 6.8m
Company Information
Established in 1970s, Zhengzhou Defy has growned into one leading drilling rig manufacturer in China, specilizing in drilling rig technology R&D, manufacturing, etc. We spark on conventional rotary drilling rig, new pneumatic drilling rig and are inventing another drilling rig with performance same as pneumatic one, but with much less investment for users.
DEFY Brand drilling rigs have been widely exported to Chile, Russia, Australia, Malaysia, Kenya, Tansanzia, Zambia, South America, Peru, Zimbabwe, etc.
FAQ
1. Q: Are you Manufacturer or Trading company?
A: We are definitely manufacturer,we design,produce and sell.We master the core technology, and constantly adjust our products according to the market trend and customer feedback, ensure product quality.
2. Q: How to buy?
A: After confirming the goods you will purchase,deposit for ordering the goods,then prodution---goods finished for confirmation,payment balance,and then shipment.
3. Q: What do I need to do after payment?
A: a) If under FOB trading terms,you need to employ a ship forwarder to ship the goods to you;
b) Under CIF trading terms,we send the goods to the destination port,and contact you to pick up the goods;All documents for customs clearance will be sent to you by international express after shipment.
4. Q: I am not familar with a new product,how to use it?
A: We provide operation manual and DVD to guide you;we also provide Free training in our factory if you were possible to come;
We provide engineers for overseas technic support;
We provide 24 hours/7 days technic support all year around.
5. Q: How can I change the broken parts if the machine got broken?
A:We provide some wearing parts for you when the first time you purchase goods from us;We also provide wearing parts for your choice.
All accessories of our machinery is available at Factory-price all Year around.
Contact Me
Please don`t hesitate to contact us if XY-400F multi usage water drilling rigs spindle drilling machine
is fit for your business.
And you are highly appreciated that if you could tell us more details of your business, then we can recommend most suitable model of drilling rig to you.
Mia Zhang
