• Model NO.：KLD - aquarium flake fish feed machine
• Brand Name：Kelid
• Type：Feed Flakes Machine
• Energy Source：Steam, Electricity
• Raw Materials：Bone Powder, Fish Meal, Corn Powder and So on.
• Product Shape：Flakes.
• Capacity：20 - 200 Kg,H
• Voltage：110 - 480 V
• Operation：Easy.
• Guarantee：12 Months After Commissioning.
• Transport Package：Inside Plastic Bag, Outside Wooden Case.
• Specification：CE,
• Trademark：Jinan Kelid Machinery Co., Ltd.
• Origin：Jinan, Shandong, China
• HS Code：84388000
• Production Capacity：250 Sets Per Month.

Basic Info.

Model NO. KLD - aquarium flake fish feed machine Brand Name Kelid Type Feed Flakes Machine Energy Source Steam, Electricity Raw Materials Bone Powder, Fish Meal, Corn Powder and So on. Product Shape Flakes. Capacity 20 - 200 Kg/H Voltage 110 - 480 V Operation Easy. Guarantee 12 Months After Commissioning. Transport Package Inside Plastic Bag, Outside Wooden Case. Specification CE, Trademark Jinan Kelid Machinery Co., Ltd. Origin Jinan, Shandong, China HS Code 84388000 Production Capacity 250 Sets Per Month.

Product Description

Aquarium Gold Fish Tropical Fish Color Flakes Fish Feed Making Machine

Introduction

Flake fish feed machine is a kind of rotating continuous drying equipment with internal heating conducting style. Certain thickness of materials film attached to the drum from material liquid vessel under the drum. Heat is transferred to the interal wall of the cylinder through pipes and then to the external wall and to materials. Dried products are then scraped off by the blade fitted on the serface of the cylinder, fall down to the sprial conveyor under the blade, and are conveyed, collected and packed.


Technical and Parameters:

Spec	Size of cylinder diameter × length(mm)	Effective heating area(m2)	Drying capacity(kg·H2O/m2·h)	Steam consumption(Kg/h)	Power of motor(Kw)	Size L×W×H(mm)	Weight(Kg)
KLD - 600	Φ600×800	1.12	40-70	100-175	2.3	1700×800×1500	850
KLD -700	Φ700×1000	1.65	60-90	150-225	3	2100×1000×1800	1210
KLD -800	Φ800×1200	2.26	90-130	225-325	4	2500×1100×1980	1700
KLD -1000	Φ1000×1400	3.30	130-190	325-475	5.5	2700×1300×2250	2100
KLD -1200	Φ1200×1500	4.24	160-250	400-625	7.5	2800×1500×2450	2650
KLD -1400	Φ1400×1600	5.28	210-310	525-775	11	3150×1700×2800	3220
KLD -1600	Φ1600×1800	6.79	270-400	675-1000	11	3350×1900×3150	4350
KLD -1800	Φ1800×2000	8.28	330-500	825-1250	15	3600×2050×3500	5100
KLD -1800A	Φ1800×2500	10.60	420-630	1050-1575	18.5	4100×2050×3500	6150

We can also supply sinking and floating fish pellet food processing machines:

Packaging & Shipping for aquarium flake fish feed machine:
Packing:  inside plastic bag, outside wooden case for aquarium flake fish feed machine (Based on the customers' need adopt the wooden case or wooden pellets, etc.).
Transportation: shipping, train, express or upon clients' demands.

Our Professional Service

1. Free Project planning and design services upon clients' special demands;

2. Overseas installation and training of equipment maintenance and operating personally;

3. Provide basic production techniques and formulas;



Our Company Information:



 Why Choose us as a reliable aquarium flake fish feed machine supplier?

1.

FAQ
1.What's your payment terms?

Our payment terms is 40% T/T as down payment, 60% by irrevocable L/C at sight or T/T before delivering.

2. What's your Guarantee?

We provide 1 year complete Guarantee and life-time maintenance service

3. How about the installation?

We will dispatch our engineers to your factory to guide you installation and commissioning work and training your operator.
Contact Information:

If you have any needs or inquiries, please feel free to contact me!
