Drilling diameter

Φ90-Φ165mm

Drilling depth

40m

Walking speed

2km/h

Hardness of rock

f=6-20

Working pressure

1.2-2.4MPa

Blast consumption

bore diameter≤Φ115 by 11.3m3/min(1.4MPa)

bore diameter≤Φ140by 13m3/min(1.4MPa)

bore diameter≤Φ165 by 17m3/min(1.4MPa)

bore diameter≤Φ140by 21m3/min(2.4MPa)

bore diameter≤Φ165 by 25m3/min(2.4MPa)

Length of pole changing

3m

Drill arm swing angle (°)

±45

Carriage swing angle(°)

±50

Carriage pitch angle

160°

Maximum horizontal drilling height

3.37M

Dusting method(apolegamy)

wet-type,Conventional dry,hydraulic

Size (mm)

6900×2200×2100(travel position)

Climbing angle

24°

Total Power

internal combustion 56kw Electric 30KW

Weight

6100kg
