GZ-50 vacuum calibrator tankX2  1TypeOne chamber 2Length6000mm 3Pipe available rangeΦ16-Φ63mm 4Vacuum pump quantity2(pcs)Yulong, Shanghai5Vacuum pump power4kw 6Direct connection centrifugal pump quantity2pcsYulong, Shanghai7Direct connection centrifugal pump power4kw 8Pipe line install methodTwo-way supply water and two-way drain water 9Water pump seal ringMechanical seal 10Front-back moving motor power0.75kw×2pcs 11Front-back moving methodLead screw driving 12Front-back moving range±400mm 13Left-right moving range±40mm 14Center height1000±50mm 15Tank materialStainless steel 16Plate thickness3mm 17Tank cover materialCast aluminium 18Cooling methodSpray 19Cooling MediumCooling water 20Spray pipe quantity4pcsX 2sets 21Nozzles quantityAbout 320pcs 22Nozzles specificationNew type 23Vacuum pump gas-water separator2pcs 24Water tank filter screen device25Flow meter3pcs 26Pipe carry methodNylon 27Outside seal plate specification16mm,∮20mm,∮25mm,∮32mm,∮40mm,∮50mm,63mm 28All fasteners inside the tank materialStainless steel 29Liquid level height control methodFloating ball, liquid level controller, 30Water pump blast hole diameter2" 31Total drain water pipe diameter2" 32In-water diameter1" 33ShapePolygon
If you want to get more information, please contact with me

Mob:+86-13962461986
