Paste Feeding Pump (SJB32-C)
Shandong Getweld Machinery and Equipment Co., Ltd.- After-sales Service：Engineer Avaliable or Online Service
- Warranty：1 Year
- Certification：CE, CSA, UL
- Power Source：Electric
- Process：Delivery
- Automatic Grade：Automatic
Base Info
- Model NO.：SJB32-C
- Application：Chocolate
- Customized：Non-Customized
- Drive：Gear
- Transport Package：Wooden Box
- Specification：CE, SGS, ISO9001
- Trademark：Lejoy
- Origin：Jiangsu, China (Mainland)
- HS Code：84382000
- Production Capacity：5 Sets ,Month
Description
Basic Info.
Model NO. SJB32-C Application Chocolate Customized Non-Customized Drive Gear Transport Package Wooden Box Specification CE, SGS, ISO9001 Trademark Lejoy Origin Jiangsu, China (Mainland) HS Code 84382000 Production Capacity 5 Sets /MonthProduct Description
For convey and lift of chocolate syrup and other cream mixtures. Main used to convey chocolate syrup from milling machine to thermal cylinder. Interlayer-sleevehot-temperature holding.
Technical Parameters:
Flow rate: 32L/min
Delivery lift: 8m
Caliber: 1.5 inch
Power: 1.5Kw
Weight: 120Kg
Dimensions: 780*390*350
| Type | Flow rate (L.min) | Delivery lift (M) | Caliber (inch) | Power (KW) | Weight (KG) | Dimension (mm) |
| SJB25-C | 25 | 8 | 1 | 0.75 | 105 | 700*300*350 |
| SJB32-C | 32 | 8 | 1.5 | 1.5 | 120 | 780*390*350 |
| SJB30-Y | 32 | 10 | 1.5 | 1.5 | 110 | 750*390*330 |
| SJB80-Y | 80 | 13 | 3 | 2.2 | 200 | 1150*450*450 |
| SJB66-T | 66 | 13 | 3 | 2.2 | 180 | 800*350*500 |
