• Model NO.：KQ 100L to 1000L
• Warranty Period：One Year
• Packing：Wooden Box
• MOQ：1 Set
• Orign：Shanghai China
• Transport Package：Plywood Box
• Specification：Follow your request
• Trademark：KAIQUAN
• Origin：Shanghai China
• HS Code：8479820090
• Production Capacity：100 Sets Per Month

Capacity Range50 Liter ~ 2000 LiterPower Supply220V 60Hz 3phase
380V 50Hz 3phaseHeating Typesteam heating, hot water heating, electric heatingTank Top StructureOptional Configurations
1.  wing top with hinged cover
2.  dish top with manway (Dome Top)
3.  flat top with removable coversBottom DesignOptional Configurations
1.  flat bottom with slight slope
2.  cone (150° conical bottom)
3.  dish end (ellipsoidal bottom)Interior Shellcylindrical vertical, 11 gauge type SS304 or SS316Interior Finish180~240 grit abrasive (food grade)Jacket(1-4 ) heating zones available, 304 full vertical side wall and bottom dimple plate jacket or spiral coil or plain jacketThermal Insulation2" polyurethane insulationTank Exterior ShellCylindrical vertical, 14 gauge type 304 or 316 stainless steelExterior FinishMatt or mirror polish Outlet1.5" or 2" sanitary milk valveAgitationworld famous brand motor with or without variable speed drive control
Side Scrape type agitation or/and Bottom sweep type agitation available,
Removable and unmovable agitator shaft available Ports2" Tri-Clover and 1.5" TC and Inlet port (s) availableLegThree or Four stainless steel pipe legs with adjustable ball feet


Heating Batch Pasteurizer Heating Tank Cooling Tank Juice Tank fermenter
