Item

Unit

Data

Max. clamping force

KN

5500

Max. opening force

mm

820

(V×H)Space between tie bars

mm

810×810

(min-max)Mould height

mm

350-820

Max. daylight

mm

1640

Ejector force

KN

150

Ejector stroke

mm

210

Ejector quantity

13

Screw diameter

mm

80

85

90

Screw L/D ratio

L/D

22.3

21

19.8

Theoretical shot volume

cm3

2141

2418

2710

Plasticising weight(PS)

g

1948

2200

2466

Injection pressure

Mpa

188

167

149

Theoretical injection rate(PS)

g

427

482

541

Plasticising capacity(PS)

g/s

80

100

118

Screw torque

N.m

5170

Max. screw rotate speed

r/min

150

Injection stroke

mm

425

Carriage push force

KN

175

Pump motor power

KW

55

Pump pressure

Mpa

16

Heating power

KW

33

Heating zone

6

Size (L×W×H)

m

8.4×2.2×2.6

Net weight

t

23.5

International designation

5500-4040
