Horizontal Directional Drilling Rig OS40
Dongguang Shengrui Packaging Machinery Co., Ltd.Base Info
Description
Diesel EngineModel Weichai-DEUTZ Power 176 KW Cylinders 6 Cooling Type Water Cooling Rotation Gears 2 Low Speed Speed of Rotation 90 RPM Torque of Spindle 16 000 Nm High Speed Speed of Rotation 180 RPM Torque of Spindle 8 000 Nm Thrust and Pullback Move Speed 2 Low Speed Force of Thrust 420 KN Force of Pullback 420 KN High Speed Force of Thrust 210 KN Force of Pullback 210 KN Other Parameters Drilling Angle 0-25º Power Winch Jaws Clamping Spindle Torque 10 000 Nm Jaws Reducing Spindle Torque 20 000 Nm Mud Pump Maximum Capacity 320 L/min Maximum Pressure 7 Mpa Drill Rod Length 3 000mm Rod Lock Φ88.5 mm Rod Body Φ76 mm Max Bending 5% Total Weight 11000 Kg Dimensions Main Machine (L×W×H) 6200×2200×2450mm
