• Production Capacity：50000PCS,Year

Basic Info.

Production Capacity 50000PCS/Year

Product Description

1. Product Description

The small-scale corn peeling and de-germination production line is the latest automatic corn grits and corn milling unit with the smallest area, the most complete functions, the simplest structure, the lowest power consumption, and the highest fineness. The production line is linearly arranged, the structure is simple, and it is easy to operate and maintain. From raw material cleaning, peeling, degerming, root removal, black umbilical cutting, crushing, making grits and flour, it can be completed all at once in one go. Only one worker needs to operate. It is a small corn flour mill with the least investment and the highest quality of finished flour.

This system removes corn skin one time in dry way (no need water), remove germ (de-germ), remove root and hilum. Separate those parts which have no nutrient and no good for taste, keep best part of corn for further processing into good quality of corn grits and flour.



2. Feature

  Cleaning, peeling, milling and sieve classifying into flour.

Cleaning machine is to remove all dirt such as iron, stone, sand, soil, hull or others.

  Peeling machine is to remove corn skin, germ, remove root and black hilum then separate these parts which has no nutrient and affect taste.

  Flour milling machine is to grind peeled corn into fine maize flour. Customer can adjust the machine and change sieve size to control fineness of the flour.

  Best peeling performance. Corn kernel peeled is skinless, de-germinated, no black hilum, very clean.

  During skin removal and de-germing, corn kernel is already polished, thus it looks nice and clean.

  Peeling system adopts alloy cylinder to peel with highest peeling precision and long time useful life, low maintenance cost.

  Unique peeling precision adjustment system. Depending on different market demand and corn type, customer can flexibly adjust the peeler to peel slightly or much. Best peeling performance rate is up to 98%.

  Peel corn one time, no need repetition, save time.

  Place on ground, module design, material feed from ground, corn kernel and bran received at ground.

  Multi-functional to peel other grains such as wheat, rice paddy, etc.



3. Technical advantages

  Use advanced maize peeling machine to produce high quality output.

  Function is powerful, including all necessary procedure that are required to produce maize flour.

  The final output flour are bright in color, with no bran, no germ (prolong shelf life of maize flour), no black hilum (for good taste), , completely exceeding customer expectations

  Adopts one layer floor stand way, easy to operate and maintain.



4. Technical parameter

Production capacity: 500kg/hour

Peeling performance rate: 98%

Motor power: 38kw

Outer dimension: 8000x1500x3500mm

Weight: 2.5Tons



5. Products Picture


Peeled corn kernel show



     Corn Flour

     Corn bran


Packing Delivery

First, the brown rice is fed to rice polisher through screw head. the surface of the rice grain is polished by friction under a certain pressure and temperature. Through the polishing treatment, not only the floating surface of the rice grain can be cleared, but also the starch is pregelatinized and gelatinized on the surface of the rice starch, and the starch gelatinization makes up for cracks, thereby obtaining the smooth appearance, improving the storage life of the rice, therefore polished rice is very necessary.





FAQ

1. What is the delivery time of this machine if we book order right now?

We will deliver your order within 30-60days depend on different of machines.

2. How do you pack this machine for exporting?

We will provide packing which is suitable for the agreed means of transportation and for the foreseeable conditions of storage at the destination.

3. How can we make inspection before delivery?

We welcome you send your inspection manager come to our factory for inspection or you can nominate international the third part inspection company.

4. What is the warranty for your machine?

If any defect or non-conformity arising from faulty design, materials, we shall eliminate defects or replace machine.

5. What is the installation requirement of this machine?

The foundation of the machine should be with sufficient strength to support the weight of the machine.

There should be enough space around the machine for maintenance and inspection.
