Basic Info.

Model NO. 90mm Transport Package Plywood Case Specification 90mm Trademark OULIN Origin China HS Code 84779000 Production Capacity 300-500 Sets Per Year

Product Description

Detail Information For Periplast Extruder 90mm Screw and Barrel for PVC:

Application: 100% PVC pellets, to produce PVC profiles.

Customer's Requirement: good abrasive& corrosive resistance

Screw's quality: nitriding quality, 38CrMoAlA as base steel.

Barrel's quality: nitriding quality, 38CrMoAlA as base steel.


Detail Information For All Single Screw and barrel for Extrusion:

Main application: be used in extrusion for film, pipe, recycling, pelleting, sheet, profiles, rod and etc.

Specification:
Diameter: Ø20mm-Ø500mm
L/D ratio: 15-53

Base material :
SKD61
42CrMo
38CrMoAlA(JIS SACM645) from BAOSTEEL company.

Heat treatment:
Advance hardening and tempering
Nitriding treatment
Mid-frequency hardening

Technical Parameters:
Nitriding depth: 0.50mm-0.80mm
Nitriding hardness: HRC56-58
Surface roughness: Ra 0.4
Screw straightness: 0.015mm
Hard chrome layer hardness: HRC58-60
Hard chrome layer thickness: 0.025-0.1mm
Alloy layer depth: 2mm-3mm
Alloy layer hardness: HRC56-64


OULIN SCREW:  YOUR LOYAL PARTNER FOR SCREW AND BARREL
