Laser Engraving and Cutting Machine
Luoyang Beeway Group- After-sales Service：Online Support, Video Technical Support
- Warranty：1 Year
- Application：Advertising Industry
- Cooling System：Water Cooling
- Technical Class：Pulse Laser
- Applicable Material：Nonmetal
Base Info
- Model NO.：R1390
- Structure Type：Gantry Type
- Laser Classification：Gaseous Laser
- Laser Technology：Laser Flame Cutting
- Engraving Machine Type：Laser Engraving Machine
- Usage：Advertising
- Power：High Power
- Drive Type：Stepper Drive
- Certification：CE
- Laser Type：CO2
- Control：Automatic
- Current：AC
- Condition：New
- 600X400mm 1000X600mm 1200X900mm 1300X900：Sealed-off Glass CO2 Laser Wavelength: 10.6um
- Transport Package：Ply-Wood Case
- Specification：CE
- Origin：China
- Production Capacity：20000units Per Year
Description
Model
R1390
Working Area
1300x900mm
Laser Type
Sealed-off Glass CO2 Laser Wavelength: 10.6um
Laser Power
40W 60W 80W 100W 150W
Laser Tube Cooling
Water cooling
Laser Output Control
0-100% No section control, Soft inner 100% adjustable.
Control System and Driver
High Speed DSP control system, stepper motor, High subdivision driver
Engraving Speed
0-1200mm/s
Cutting Speed
0-600mm/s
Voltage
AC220V/110V 50HZ/60HZ
Reposition Accuracy
<±0.01mm
Minimum Letter Size
Chinese: 1.5mm English: 1mm
Machine Power
<1000W
Rise and Fall Height
100mm (adjusted manually)
Working Environment
Temperature: 045 °C Humidity 5%95% (No condensate water)
Warranty
Supported Format and Software
12 Months (3 months for laser tube)
PLTDSTDXFBMPAI Support AutoCADCorel Draw output directly
