Max.Drilling Diameter  Uncased(mm)φ2500Cased(mm)φ2200Max.Drilling Depth(m)102Dimension  Working condition L × W × H(mm)11000X4800X24586Transportation condition L × W × H(mm)18880×3500×3820Overall Drilling Weight(t)90Engine  Model-CUMMINS QSM11-C400Rated Power(kW)298/2100Hydraulic System  Working pressure(MPa)33Rotary Drive  Max. output torque(kN.m)360Rotary speed(r/min)6~25Spin off speed(r/min)-Pull-Down Cylinder  Max.pull-down piston push(kN)240Max.pull-down piston pull(kN)250Max.pull-down piston stroke(mm)6000
 Main Technical SpecificationEngine Model CUMMINS B5.9-C Rated PowerkW133 Rotary Drive Max. output torquekN·m150 Rotary speedr/min6~28 Max. Drilling Diametermm1300,1500 Max. Drilling Depthm48,55 Pull-Down Cylinder Max.pull-down piston pushkN120 Max.pull-down piston pullkN160 Max.pull-down piston strokem3.5 Main Winch Max.Pulling forcekN145 Max.line speedm/min75 Auxiliary Winch Max.Pulling forcekN50 Max.line speedm/min60Mast Rake Side/forwards/backwards±3°/5°/15° Undercarrige Max. traveling speedkm/h3.2 Max.grade ability%40 Min. Clearancemm352 Track shoe widthmm800 Distance between tracksmm3200~4200Hydraulic System Working pressureMpa32 Overall Drilling Weightt47 Dimension Working conditionmm7122X4200X17250 Transportation conditionmm12300X3200X3060






Company profile
XCMG is a construction machinery manufacturer with over 70 years of experience. Over the years, we have grown to become the world's most comprehensive construction machinery manufacturer and influential multinational company. In 2019, we rank No.1 in China and No. 5 in global heavy equipment industry.XCMG's construction machinery covers an astonishing range of equipment, including cranes, earth-moving  machinery, road machinery, excavators, concrete machinery, mining machinery, piling machinery, lumber machinery, fire-fighting machinery, heavy trucks, sanitation machinery, agricultural machinery, and more. We have the world's most comprehensive product line, and offer customers complete solutions for construction equipment.  Our other businesses include finance, leasing, and remanufacturing.
