Model

YG-130

YG-200

YG-300

YG-400

Weight(Ton)

3

5.5

9

10

Drilling Diameter(mm)

100~219

140~305

140~325

140~350

Drilling Depth(mm)

130

200

300

400

Walking Speed(Km/h)

0.8

2.5

2.5

2.5

Climbing Angles

30

30

30

30

Power(Kw)

32

65

84

95

Pressure(Mpa)

1.45~2.5

1.7~3.0

1.7~3.3

1.7~3.5

Air Consumption(m³/Min)

15~29

17~30

17~35

17~35

Drilling Pipe Length(M)

1/1.5

1.5/2.0/3.0

1.5/2.0/3.0

1.5/2.0/3.0

Rig Lifting Force(T)

5

18

28

24

Dimension

4000*1450

*2050

3800*1700

*2350

5500*1950

*2780

5200*2000

*2780

Packing&shipment of drilling rigs machine:
Company&Team:
