Diamond Saw Blade Silent Type for Marble Cutting/Diamond Tools/Cutting Disc
Pinghu Kaixin Plastic Industry Co., Ltd.- Blade Type：Segmented
- Manufacturing Process：Brazed
- Application：Marble
- Customized：Customized
- Suitable：Wet Cutting
- Transportation：Ocean, Land, Air
Base Info
- Model NO.：SMBB
- Steel Core：Sanwich Steel Core
- Certificate：En13236
- Transport Package：Carton
- Specification：250x10x60mm
- Trademark：COREDIAM
- Origin：China
- HS Code：82023910
- Production Capacity：500PCS,Month
Description
Basic Info.
Model NO. SMBB Steel Core Sanwich Steel Core Certificate En13236 Transport Package Carton Specification 250x10x60mm Trademark COREDIAM Origin China HS Code 82023910 Production Capacity 500PCS/MonthProduct Description
1. IntroductionThis type blade is with sandwich steel core, which can reduce noise in working. Marble saw blades are usually brazed. In common case, its segment height is 10mm. It is installed on stone saw, tile saw, masonry saw for wet cutting marble and other stones. Its common sizes range from 10-inch to 24-inch. Special specifications are also available according to your request. We also offer full OEM service, and help to design finishing packages with your own logo.
2. Features:
- With sandwich steel core, low noise.
-Narrow U slot can make the fast and smooth cutting.
-It has good sharpness and high efficiency in the process of cutting, the segments are not easy to fall off during work.
-It has a long lifespan.
-Good cutting result: smooth cutting, flat surface, and even size. Stable cutting, narrow cutting gap, stone waste reduction.
3. Production process.
Raw material→ powder mixing → Steel core process → cold press → segment sintering → welding → surface treatment → package → dispatch
4. Delivery time.
Sample delivery: If we have stock, the delivery time is within one week after we got your sample payment.
If we don't have stock, the delivery time will depend on the sample production.
For batch order, delivery time is usually 3-4 weeks after order confirmation and payment.
Size data are as below:
| Item No. | Diameter | Segment Height | Segment Width | Arbor |
| SMBB25010 | 250mm | 10mm | 3.0mm | 60mm |
| SMBB30010 | 300mm | 10mm | 3.2mm | 60mm |
| SMBB35010 | 350mm | 10mm | 3.2mm | 60mm |
| SMBB40010 | 400mm | 10mm | 3.4mm | 60mm |
| SMBB45010 | 450mm | 10mm | 3.6mm | 60mm |
| SMBB50010 | 500mm | 10mm | 3.6mm | 60mm |
| SMBB60010 | 600mm | 10mm | 4.0mm | 60mm |
