Main Technical ParametersModel
MD-H45/50MD-H55MD-H60MD-H65Suitable Material
HDPEMax Film Width(mm)
60080010001200Film Thickness(mm)
HD:0.008-0.08Max Extrusion Output HD
30/40kg/hr50kg/hr60kg/hr80kg/hrExtrusion unit  Gear Box
133/146173173200Screw Diameter(mm)
φ45/50φ55φ60φ65Screw L/D Ratio
28:128:128:128:1Screw's Material
38 CRMOALABarrel's Material
38 CRMOALABarrel's Cooling Fan
250W×2370W×2370×2370×3Thermo Control (zone)
3334Driving Motor (kw)
7.5/1118.52230Extrusion Die  Die Size (mm)
HD:φ60/80HD:φ80/100HD:φ100/120HD:φ120/φ150Screen Changer
Standard manualThermo Control (zone)
2222Air Ring  (mm)
φ620φ620φ620φ760Cooling Blower (kw)
1.52.22.23Center Steady Stick
1 PCSTake-UP Unit   Roller Width (mm)
φ138×650φ138×850φ138×1100φ138×1300Embossing Roller Width
550mm750mm1000mm1200mmTake-UP Motor (kw)
0.751.11.11.5Take-UP Speed(M/min)
10-6010-6010-6010-60Height adjustable type
700mmWinding Unit   Type OF Winder
Surface Friction Single WinderRoller Width (mm)
70090011001300Winding Motor (N.M)
6101016Winding Speed(M/min)
10-6010-6010-6010-60Voltage
380V, 50HZ, 3PHASECover Dimensions (m)
4.5×2.0×4.34.5×2.2×4.55×2.5×4.85.5×2.8×5.2
