| NAME | SPEC. |
|---|
| Torque(KN.M) | 280 |
| Drilling Diameter(mm) | 2500 |
| Drilling Depth(m) | inter-locking | 58/62 |
| Friction | 88/94 |
| Drilling Speed(r/min) | 5~28 |
| Engine Model | Cumins QSM11 |
| Rated Power(kw) | 298 |
| Rated Engine Speed(r/min) | 2100 |
| Max.Crowd Force(kN) | 260 |
| Max.Crowd Cylinder Pull(kN) | 260 |
| Line Pull(main winch)(kN) | 290 |
| Line Speed(main winch)(m/min) | 68 |
| Line Pull(aux.winch)(kN) | 90 |
| Line Speed(aux.winch)(m/min) | 66 |
| Operating Mass(t) | 93 |
| Traction Force(kN) | 557 |
| Rope diameter(Main winch)(mm) | 32 |
| Rope diameter(auxiliary winch)(mm) | 22 |
