Model

SJCO-50

SJCO-55

SJCO-65

Features

Raw Material

HDPE, LDPE, LLDPE; Virgin and Recycled

Film Width

800mm

1200mm

1500mm

Average Output

70Kgs

85Kgs

90Kgs

Film Thickness

0.008mm-0.15mm

Power supply

380V, 3Phase, 50Hz

Weight

2000KG

2500KG

3000KG

Dimension

4.5M×4M×4.5M

4.5M×4M×6M

6M×5M×6M

Extrusion Unit

Screw& Barrel Diameter

50mm×2

55mm×2

65mm×2

Screw& Barrel L/D ratio

30:1

32:1

Motor

11KW×2

15KW×2

18.5KW×2

Gearbox

146/146

173/173

200/200

Die Head Type

Rotary Die Head

Die Size

280/200mm

320/200mm

350/280mm

Heating

20KW

25KW

35JKW

Blower

3KW×2

Film
Taking-up Tower

Upper Tower Type

Rise and Fall

Roller Length

900mm

1400mm

1700mm

Roller Working Way

Opened and Tightened by Air Cylinders

Take Up Motor

1.5KW

Winding Station

Winder Type

Double winding station

Rollers Length

1000mm

1400mm

1700mm

Torque Motor

15N/M×3

Max. Winding Diameter

600mm

Control Panel

Electronics

Top China Brand

Inverter Capacity

11KW/1.5KW

15KW/1.5KW

22KW/1.5KW

Optional Equipment

Hopper loader, Corona, Mechanical Screen Changer
