Work Stationsstations2 Clamping Forcekgf150000 Mould PlateSizemm2(290X550) Mould Heightmm100-210 Mould-Opening Strokemm350 Heating Powerkw8.04 Injection SystemInjector1Diameter of Screwmm60Injection Cap (Max)cc860Injection Pressurekg/cm260-110Injection Speedcm/sec0-10Rotating Speed of Screwr.p.m0-190Temperature Controlsection4Heater Barrelkw6.05Heating Platekw25.6Hydraulic Systemkw22Vacuum Pumpkw2.2Cooling Fan of BarrelHP1Total Electricitykw50Oil Tank SizeL500Machine Weightkg80001.Low operation height,Operation height in accord with human engineering
2.Extra height opening stroke.
Act by fixed opening stroke: 350mm, which is not affected by any mould thickness changes and
3.available for 2plates mould,Mould thickness adjusting mechanism
Mould adjusting scope: 100-200MM.

4.Rapid mould opening ,Act by toggle mechanism which opens the mould rapidly
5.Speedy injector movement
Driven by linear-track, allowing speedy moving and precise positioning,Energy saving design
6.No need water circulation for mould station
7.Space saving design,Put oil tank together with injection base, which makes the structure compact and saves more space.

FAQ:
1.Do the machine parts use well-know brands?
Yes, such as Hitech , Omron and so on.
2.What kind of plastic material can be used on your machines?
EVA PVC and other general material could be used on our  machine.
3.What kind of shipping container for this machine?
Container choose will depends on the different machine size . 20HQ,40HQ,40GP will suitable for different size machine.
