• Model NO.：GYWB-300
• Material：Stainless Steel
• Turn-Key Project：Yes
• Capacity：100-500kg Per Hour
• Brand：Genyond
• Transport Package：Wooden Case
• Specification：ISO9001
• Trademark：Genyond
• Origin：Shanghai, China
• HS Code：84381000
• Production Capacity：10 Sets Per Month

Basic Info.

Model NO. GYWB-300 Material Stainless Steel Turn-Key Project Yes Capacity 100-500kg Per Hour Brand Genyond Transport Package Wooden Case Specification ISO9001 Trademark Genyond Origin Shanghai, China HS Code 84381000 Production Capacity 10 Sets Per Month

Product Description

Wafer Machine
Full-automatic wafer machine is designed and manufactured according to the facts of domestic biscuit manufacturing industry and absorbing the most well-known wafer production lines of many oversea manufacturers, which features reliable performance,compact structure,small occupation,high yield,lower energy consumption,convenient maintenance,simple operation.

It consists of baking oven,cooling tower,sheet picking machine,cream spreading machine,cooling cabinet,cutting machine,batter mixer,cream mixer and smash machine.

The driven motors adopt SEW Germany, the bearings use SKF Fracne. Operating system uses PLC programing to make the process automated and easy control.

Description:

1. Brand: genyond Brand (famous foodstuff machinery brand in China)
2. Function: produce the different kinds of wafer automatically.
3. Capacity: 2.18 tons to 6.84tons/per hour.
4. Manufacture experiences: 15 years.
5. Baking type:  a) Gas (LNG or LPG);
6. Whole shell of line use N304 stainless stell in accordance with health and safety standard.
7. Electricity and transmission all made by  Siemens, Mitsubishi.
8. Bearing brand: SKF Franch/Austria
9. Motor brand: SEW Germany

Technical Data:


Models	27	33	39	45	51	65	69	75
Baking Oven Length(mm)	6000	7150	8300	9450	10600	13300	14000	16000
Whole Line Length(mm)	22000	23150	24300	25450	26600	29300	30000	35400
Power (Kw)	5.52	5.52	5.52	5.52	5.52	8.12	8.12	8.12
Consumption LNG(m3/h)	21	26	30	35	40	50	54	58
Capacity(pcs/min)	14	17	20	23	26	33	35	38

Parameter:
1) The standard size of the baking plate is 470*325mm;  Pattern(standard) is 2.5*2.5*0.5mm;
     The max size of baking plate: 500mm*350mm;
2) The size of wafer sheet is 464*321mm; The effective cutting size of wafer sheet is 456*315mm;
3) Wafer sheet's thickness: 2.5mm---3.2mm;
4) Weight of wafer sheet: 50---60g;

Production Process:
Production Process of wafer biscuit machine: batter mixing----wafer baking----cooling----cream spreading----book cooling----cutting

PRODUCTION UNIT
Main parts of production line
*Baking oven
This baking oven consists of batter injection system, gas heating system and gas leaking alarm system, plates' transferring and connecting devices, is full metal structure with perfect heat preservation, with elegantappearance. Observation windows are set for each heating area to facilitate the inspection of production, the burner is redesigned and adopts state of art energy-saving burning technology to improve the heat efficiency greatly. The temperature in the oven is uniform.

*Cream spreading machine(Single head)
Spreading cream on surface of wafer sheet by pressing roller.
The cream hopper with heating device keeping the hopper temperature

*Cutting and laminating machine
 Laminate the wafer sheet and cutting wafer  sheet into wafer bar as per demand

After sales service:
1. Warranty period: one year.
2. Installation: we will send our trained specialists to install the machines and train the customer's worker when the equipments are arrived in the client's city.
3. If the machines have something wrong, we will help you to solve the problem anytime.
