• Model NO.：KQ-1000
• Application：Milk, Yogurt
• Customized：Customized
• Name and Description：High Pressure Homogenizer Cream Homogenizer Indus
• Material：Stainless Steel 304 , 316
• Applications：Homogenize Milk, Yogurt, Icecream, Juice,Chemical
• Flow Ralte：500~10000L,H
• Processing Pressure：25~100MPa
• Motor Power：5.5-110kw
• Working Life：More Than 10years
• Pressure：25MPa, 40MPa, 70MPa
• Certificated：Ce Certificate
• Food Industry Homogenizer：Sanitary Contacting Parts
• Packing：Wooden Box
• Spare Parts：Available
• MOQ：1set
• OEM：Yes
• After Service：One Year ,Two Years .
• Transport Package：Standard Wooden Box
• Specification：CE
• Trademark：KAIQUAN
• Origin：Shanghai, China
• HS Code：8479820090
• Production Capacity：100 Units,Month

             Model No.
Technical
parameter
KQ0.5-25
KQ1-25
KQ1.5-25
KQ2-25
KQ2.5-25GJB3000-25
KQ3-25
KQ5-25Rated pressure(MPa)25252525252525Rated flow(Liters/H)500100015002000250030005000Medium temperature(ºC)≤85≤85≤85≤85≤85≤85≤85Feeding pipe diameter(mm)25252525253240Discharge pipe diameter(mm)15152020202025Power of motor(Kw)5.57.5111518.52245
 Volt and Electricity Flow380V,50HZ,3PH380V,50HZ,3PH380V,50HZ 380V,50HZ220V,60HZ,3PH380V,50HZ380V,50HZOutline dimension (m)
Length * width * height1.16×0.9×1.241.16×0.9×1.24
 1.16×0.9×1.24
 1.4×1.1×1.421.4×1.1×1.421.4×1.1×1.422.2×1.45×1.1
 Weight(Tons)0.40.51.251.251.251.251.7Unit price FOB Shanghai(USD)USD$3300USD$3,500USD$3,700USD$6,800USD$7,500USD$7,700USD$12,300Milk homogenizer pressure through an adjustable current-limiting gap process, the formation of loss of pressure expansion, explosion, shear, combined effect of high-speed collision, the particles and liquid droplets shatter into very small size, while creating an ideal solution or dispersion of emulsion. Product stability, consistency, mixed, and easy absorption, nutritional value, shelf life, flavor, color, security activities are realized in the homogeneous process. Widely used in food, dairy, beverage, pharmaceutical, fine chemicals and bio-technology and other fields of production, scientific research and technological development.

(1)Liquid solidification(powder) homogeneous substance into steady dispersed liquid(homogeneous fluid), which is applicable to drink&food industry, such as ice cream, dairy products, catchup, jam, coco, coffee, juice tea, vegetable proteins drink, soft drinks, chocolate milk, natural food color and essence soy milk powder.
(2)Apply for cosmetic, facial washing milk, lipstick, skin cream, hair-tonic, perfume, shampoo, hair permanent water and so on.
(3)To smash the biology cells or new products, and the emulsification made from liquid-liquid homogeneous oli or water applying for the biotechnology: Barm and other fungoids or apply for smashing alga cellulars and so on.
(4)Apply for the mainline liquid of pharmacy, oral liquid, ointment, tablet, fat milk and so on.
(5)Apply for chemical lines, pesticide, coating, antisepsis emulsion dye, resin, rubber latex, film showing color liquid, viscidity additive, and grease, lithium grease, silicone polymer latex and silicone dying liquid.

Welcome to visit our factory in the future !
