Hydraulic Motor Low Speed High Torque Replace with Sai GM Series
Guangzhou Sundy Commercial Co., Ltd.- Certification：CE, ISO9001
- Speed：Low Speed
- Type：Hydraulic Motor
- Hydraulic Valve：Switch Control Valve
- Auxiliary Components：Pipe and Pipe Fittings
- Hydraulic Fluid：Mineral Oil
Base Info
- Model NO.：gm
- Flow Control Valve：Shunt Flow Valve
- Pressure Control Valve：Sequence Valve
- Hydraulic Motor：Piston Hydraulic Motor
- Hydraulic Actuator：Swing Hydraulic Cylinder
- Hydraulic Power Units：Gear Pump
- Transport Package：in Plywood Case
- Specification：ISO9001
- Trademark：Hyphen
- Origin：China
- HS Code：8412291000
- Production Capacity：5000PCS,Year
Description
HGM Series(Technical Data)
TYPETheoretical Pressure(Mpa) Torque(N.m) (Speed) (Weight) (ml/r) (MPa)
Rated (MPa)
Peak Rated Unit torque (R/min)
Con. (r/min)
Max. (kg) Displacement (N.m/Mpa)
HGM05-60 59 25 45 235 9.4 1-700 1000 22 HGM05-75 74 25 42.5 295 11.8 1-700 1000 HGM05-90 86 25 37.5 343 13.7 1-700 1000 HGM05-110 115 25 40 458 18.3 1-650 900 HGM05-130 129 25 37.5 513 20 1-650 900 HGM05-150 151 25 32.5 600 24 1-650 900 HGM05-170 166 25 32.5 660 26.4 1-600 800 HGM05-200 191 25 28 760 30.4 1-600 800 HGM1-100 99 25 42.5 385 15.4 1-550 1000 31 HGM1-150 154 25 40 600 24 1-550 1000 HGM1-175 172 25 37.5 670 26.8 1-550 900 HGM1-200 201 25 35 785 31.4 1-550 800 HGM1-250 243 25 35 950 38 1-450 700 HGM1-300 290 25 30 1130 45.2 1-350 650 HGM1-320 314 25 28 1225 49 1-350 600 HGM2-200 192 25 42.5 750 30 0.7-550 800 51 HGM2-250 251 25 42.5 980 39.2 0.7-550 800 HGM2-300 304 25 40 1188 47.5 0.7-500 750 HGM2-350 347 25 37.5 1355 54.2 0.7-500 750 HGM2-420 425 25 35 1658 66.3 0.7-450 750 HGM2-500 493 25 35 1923 76.9 0.7-450 700 HGM2-600 565 25 30 2208 88.3 0.7-450 700 HGM2-630 623 25 28 2433 97.3 0.7-400 650 HGM3-425 426 25 42.5 1660 66.4 0.5-500 650 87 HGM3-500 486 25 42.5 1895 75.8 0.5-450 600 HGM3-600 595 25 40 2320 92.8 0.5-450 575 HGM3-700 690 25 35 2700 108 0.5-400 500 HGM3-800 792 25 35 3100 124 0.5-400 500 HGM3-900 873 25 35 3400 136 0.5-350 400 HGM3-1000 987 25 28 3850 154 0.5-300 350 HGM4-600 616 25 40 2403 96.1 0.4-400 550 120 HGM4-800 793 25 40 3100 124 0.4-350 550 HGM4-900 904 25 37.5 3525 141 0.4-325 450 HGM4-1000 1022 25 35 4000 160 0.4-300 400 HGM4-1100 1116 25 35 4350 174 0.4-275 400 HGM4-1300 1316 25 28 5125 205 0.4-225 350 HGM5-800 807 25 42.5 3150 126 0.3-325 450 175 HGM5-1000 1039 25 42.5 4050 162 0.3-300 450 HGM5-1200 1185 25 40 4625 185 0.3-300 400 HGM5-1300 1340 25 40 5225 209 0.3-300 400 HGM5-1450 1462 25 37.5 5700 228 0.3-275 350 HGM5-1600 1634 25 37.5 6350 254 0.3-250 300 HGM5-1800 1816 25 35 7075 283 0.3-250 300 HGM5-2000 2007 25 35 7825 313 0.3-200 250 HGM6-1700 1690 25 45 6600 264 0.2-250 400 275 HGM6-2100 2127 25 40 8300 332 0.2-225 350 HGM6-2500 2513 25 35 9800 392 0.2-200 300 HGM6-3000 3041 25 30 11875 475 0.2-175 250
TYPE
Rated
Peak
Con.
Max.
