Sjsz65/132 PVC Pipe/Profile/Sheet/Board Conical Double Screw Extruder/Plastic ...
Ningbo Zhaoke Int'l Imp. & Exp. CorpBase Info
Description
Screw rotation directionScrew rotation speed (rpm) 1-37 1-32 1-34.7 1-36.9 1-32.9 Effective length of screw (mm) 985 1070 1440 1800 2500 Power of Main engine (kw) 15 18.5 37 55 90 Barrel heating power (kw) 12 18 24 36 86.8 Production capacity (kg/h) 95 80-120 250-300 320-450 500-600 Center height (mm) 1000 1000 1000 1000 1200 Net weight (kg) 2800 3200 4000 5000 10000 Dimensions (mm) (L*W*H) 3620*1050*2157 3000*1050*2200 4235*1520*2450 4750*1550*2460 6725*1550*2841
