Truck Mounted Drilling Rig Xj350 for Workover with 3200m
Ruian City Jiayuan Machinery Co., Ltd.Base Info
Description
3,200m (10,500ft, 2-7/8″DP)2,500m (8,200ft, 3-1/2″DP) Servicing Depth 4,000m (13,120ft, 2-7/8″EUE Tubing) Rated Hook Load 600kN (134,900 lbf) Max. Hook Load 900kN (202,330 lbf) Traveling System 3×4 {Φ26mm (1'') Wireline} Hook Hoisting Speed 0.25~1.4m/s (0.82~4.6ft/s) Overall Dimensions(l×w×h) 18.5×2.9×4.2m60.7ft×9.5ft×13.8 ft 18.5×2.85×4.2m60.7×9.4×13.8ft Total Weight 51,000kg (112,440 lb) 49,500kg (109,130 lb) Max.Travel Speed 45km/h (28mil/h) Carrier Self-propeller 10×8 Engine Model andRated Power C9260kW (350hp)/2100rpm S6063298kW (400hp)/2100rpm Transmission Allison 4700 OFS Allison M5610s Height 31.7m (104ft) Max. Static Load 900kN (202,330 lbf) Racking Board Capacity 4,000m (13,120 ft, 2-7/8″EUE Tubing) Racking board Height 16.8m (55 ft) Drawwork Rated Power 224kW (300hp, Double drum) 238kW (320hp) Main Drum Φ406×890mm (Φ16″×35'') Φ429×965mm (Φ16.9″×38'') Max. Faster Line Pull 180kN (40,470 lbf ) Sanding Drum Φ965×264mm (Φ38″×10.4'') Air Assist Brake System KOBELT Disc4-7-35″ Caliper 5026-CM KOBELT Disc4-7-48″ Caliper 5026-CM Drill Floor (l×w×h) 4.2×4.2×3.7m (13.8×13.8×12.1 ft) Swivel Model and Max. Load SL90 900kN (202,330 lbf) ZP125 Rotary Table
Packing & Delivery
FAQ
Max. Load 900 kN (202, 330 lbf
Max. Open Dia. 292mm (11.5")
