Model

SJCOT-55

SJCOT-60

SJCOT-65

Features

Raw Material

HDPE, LDPE, LLDPE; Virgin and Recycled

Film Width

800mm

1500mm

2000mm

Average Output

80Kgs

120Kgs

150Kgs

Film Thickness

0.008mm-0.15mm

Power supply

380V, 3Phase, 50Hz

Weight

3000KG

3500KG

4000KG

Dimension

6M×5M×5.5M

6M×6M×6M

6M×7M×7.5M

Extrusion Unit

Screw& Barrel Diameter

50mm×2
55mm×1

55mm×2
60mm×1

60mm×2
65mm×1

Screw& Barrel L/D ratio

32:1

Motor

15KW×2
22KW×1

18.5KW×2
30KW×1

30KW×2
45KW×1

Gearbox

146/173

146/173

173

Die Head Type

Rotary Die Head

Die Size

400MM

450MM

600MM

Heating

50kw

60kw

80kw

Blower

7.5KW

Film
Taking-up Tower

Upper Tower Type

Rise and Fall

Roller Length

1000mm

1700mm

2200mm

Roller Working Way

Opened and Tightened by Air Cylinders

Take Up Motor

1.5KW

Winding Station

Winder Type

Double winding station

Rollers Length

1000mm

1700mm

2200mm

Torque Motor

15N/M×3

Max. Winding Diameter

600mm

Control Panel

Electronics

Top China Brand

Inverter

3pcs

Optional Equipment

Hopper loader, Corona, Mechanical Screen Changer
