Agricultural Machine Standard Tr2008asae Tie-Rod Hydraulic Cylinders

Jordon Gift Co., Ltd.

Certification：ISO9001
Pressure：Medium Pressure
Work Temperature：Normal Temperature
Acting Way：Double Acting
Working Method：Straight Trip
Adjusted Form：Regulated Type

Base Info

Model NO.：TR2008ASAE
Structure：Piston Type
Material：Carbon Steel
Application：Agricultural Harvester
Seals：Parker, Hallite
Warranty：1 Year
Working Pressure：3000psi
Transport Package：Plywood Case
Specification：2"x8"
Origin：China
HS Code：84122100

Description

Part no.Bore sizeStrokeRodColumnEstimateloadship Wt.(lbs.)TR20082"8"1 1/8"2500PSI19.1 TR25082.5"10"1 1/8"2500PSI22.5 TR30083"8"1 1/4"2500PSI26.7 TR30163"16"1 3/8"2500PSI24.5 TR2T35083.5"8"1 1/4"2500PSI36.0 TR35163.5"16"1 1/2"2500PSI46.1 TR40084"8"1 1/2"2500PSI38.0 TR40164"16"1 3/4"2500PSI55.2 TR50085"8"1 1/2"2500PSI48.5 TR50165"16"2"2500PSI63.8

Custom Hydraulic Cylinder

We can supply customized hydraulic cylinders with drawings or samples, or if you could provide following specification:

•diameter of bore & rod
•stroke
•mounting style
•mounting distance
•working pressure
•ports
•seals
•special modifications.

Qingdao GD Machinery CO.,LTD.

Product

tie rod hydraulic cylinder, welded hydraulic cylinder, telescopic cylinders cylinder,

flange type hydraulic cylinder, hydraulic cylinder with valve function,

hydraulic power unit, Hydraulic manifold block, pneumatic fitting,

Material

Tube - Cold Drawn Precision seamless Tubing
End Caps - Steel, threaded fixed;
Wear Ring - Nylon Backup Washer
Rod Seals - Polyurethane U-Cap
Rod - Chromed, ground & polished piston rod

Mounts - Trunnion with angular Swivels
Rod Wiper - Polyurethane

Application

Agriculture, Concrete & Asphalt, Cranes, Fire & Rescue,

Forestry & Logging,Mining & Rock Crushing,Oil & Gas,

Snow & Ice Control,Waste Management and Material Recycling Industry ,

Engineering Equipment, Special Vehicle

Feature

1.High quality with a reasonable price

2.ISO9001-2008

3.Customized specification are accepted

Payment

T/T;L/C,WESTERN UNION.
