Plastic Shredder/Plastic Crusher/Single Shaft Shredder/HDPE Pipe Shredder/Plastic ...
Hongri Industrial Measures Co., Ltd.Base Info
Description
Basic Info.
Model NO. xjg Transport Package Wooden Specification sgs Trademark XJG Origin Zhangjiagang HS Code 847780000 Production Capacity UncertainProduct Description
Plastic Crusher/Pipe Shredder/Pipe Crusher
Main applications:
This machine is suitable for PVC, PE, PP wide panel.
1. Certificate: CE&ISO9001: 2000
2. Warranty period: 12months
3. Main export markets: Turkey, Ukraine, Saudi Arabia, Russia, Canada, Brazil, Iran,
The SWP400 crusher suit for plastic pipe, profiled bar and Board
1. The SWP400 crusher suit for plastic pipe, profiled bar and Board
1. The SWP400 crusher suit for plastic pipe, profiled bar and Board
1. Main technical parameters
Diameter of rotating bit: φ 400mm
Quantity of rotating bit: 3
Quantity of fixed bit: 2
Crushing capacity: 450kg/h (according to different materials)
Diameter of mesh hole: φ 10 mm
Power: 3-phase 380V 50Hz
Size of inlet: 375× 320mm
Outline dimension: 2500× 1200× 2000mm(L× W× H)
Weight of equipment: 980kg
| Model | SWP550 |
| Diameter of rotating blade | 550 |
| Rotating blade quantity | 5*2pcs |
| Rotating speed of rotating blade (r/min) | 520 |
| Fixed blade quantity | 2*2pcs |
| Aperture of screen (mm) | 10 |
| Gringding capacity (kg/h) | 350-500 |
| Power (kw) | 37 |
| Power source | 3phase 380v50hZ |
| Aperture of feed inlet (mm) | 1050*860 |
| Machine weight (kg) | 300 |
