• Model NO.：1T-10T
• Material：Ss316L
• Transport Package：Normal Export Package
• Specification：1T-10T
• Trademark：Tianlong
• Origin：Wenzhou, China
• Production Capacity：100sets Per Month

Basic Info.

Model NO. 1T-10T Material Ss316L Transport Package Normal Export Package Specification 1T-10T Trademark Tianlong Origin Wenzhou, China Production Capacity 100sets Per Month

Product Description

Adopt Siemens PLC for automatic detection for levels of cleaning liquids temperatures,acid and alkali concentration in CIP station.Man-machine dialogs can be camed out through Siemens PLC.To input all parameters required by technologies by touch screen directly. Automatic water compensation,appending of thick acid and alkali,heating on CIP stations can be completed according to parameter set and working flows chosen.Then indicators of various conditions and alarming detectors of concentration,temperature and level int the station are of famous international brands,all are highly reliable and precise . By detecting components on flowing loop.we can judge whether certain liquid is reclaimed completely. which reduce consumption of  cleaning liquids,water and cost.






Advantages:full-automatic operator reduces humans labor cost and producing cost greatly.Most updated man machine dialog (visual) operating mode ,highly humanrized , makes it easier for operators in training to learn how to operate.Accurate control on temperature ,level and concentration on CIP station reduces consumption of steam and water greatly.and precise control on concentration improves utilization of cleaning liquids greatly.

Disadvantages:remarkable capital investment.It is not easy to detect and find faults when operated wrongly.Requirements on maintenance technicians are high.

For it is highly automatized , it is a good choice for large enterprises of food industry in china.



Note:1.Plate heating type: heat exchanging efficientcy of plate is high,which reduces steam consumption and cost.Coil-pipe heating type:heat-exchanging efficiency is lower than plate heating type.but its invested cost is less than plate heating type.(Can be attached with steam-through heating).
2.All specifications of joint type have systems of three basic types of tanks (including acid tank,alkali tank and hot water tank).All specifications of split type are of systems of three types,four types and five types of tanks.
