• Model NO.：GJB Series
• Name：Spare Parts Available Two Stage 4 Plunger Ketchup
• Usage：Homogenize Milk, Yogurt, Icecream, Juice,Chemical
• Product Material：Stainless Steel 304,316
• Manual Book：Yes
• Working Pressure：25MPa ,30MPa ,40MPa
• Motor Power：5.5-75kw
• Flow Ralte：500~10000L,H
• Stage：Two Stage
• Certificate：Ce Approved
• Food Industry Homogenizer：Sanitary Contacting Parts
• Motor Brand：Siemens ,ABB,China Brand
• Voltage：Make It to Your Order
• Plunger：4 to 5 Plunger
• MOQ：1set
• Working Life：More Than 10 Years
• Transport Package：Standard Wooden Box
• Specification：CE
• Trademark：KAIQUAN
• Origin：Shanghai, China
• HS Code：8479820090
• Production Capacity：100units,Month

             Model No.
Technical
parameter
KQ0.5-25
KQ1-25
KQ1.5-25
KQ2-25
KQ2.5-25GJB3000-25
KQ3-25
KQ5-25Rated pressure(MPa)25252525252525Rated flow(Liters/H)500100015002000250030005000Medium temperature(ºC)≤85≤85≤85≤85≤85≤85≤85Feeding pipe diameter(mm)25252525253240Discharge pipe diameter(mm)15152020202025Power of motor(Kw)5.57.5111518.52245
 Volt and Electricity Flow380V,50HZ,3PH380V,50HZ,3PH380V,50HZ380V,50HZ220V,60HZ,3PH380V,50HZ380V,50HZOutline dimension (m)
Length * width * height1.16×0.9×1.241.16×0.9×1.24
 1.16×0.9×1.24
 1.4×1.1×1.421.4×1.1×1.421.4×1.1×1.422.2×1.45×1.1
 Weight(Tons)0.40.51.251.251.251.251.7





Spare Parts Available Two Stage 4 Plunger Ketchup Yogurt Milk Homogenizer .
