Basic Info.

Model NO. AF-65 Application Gasket Transport Package Wood Package Specification CE Trademark YAOAN (ANFU) Origin Dongguan HS Code 8477209 Production Capacity 100 Sets Per Month

Product Description

Eco-friendly PVC edge banding machine

PVC Magnetic gasket production line

1. Φ50mm extruder: One set

Hopper dryer: one set

Automatic loading system: one set

Screw dia: 50mm

Screw L/D: 28: 1

Screw type: special screw (applicable for PVC granule).

Screw material: 38CrMoLALA

Nitration depth: 0.7mm

Barrel material: 38CrMoLALA

Nitration hardness: HV940

Control power: 15kw

Control style: frequency conversion (It adopts Taiwan's Delta inverter)

Gear box: one set

Thermostat zone: 5 zones

It adopts Japanese RKC temperature controller, temp. tolerance: ±1°C.

Radiating zone: 3 zones

It adopts Taiwan's high-efficiency, low-noise air blower for cooling.

Electric control cabinet: one set

AC contactor is of Taiwan's brand

 Leaner speed: 2-12m/min



2. Extruding die: one set

 Magnet strip size: 2.5x8mm

Note: this quotation just contain 1 specification



3. Stainless steel cooling water trough: one set

Length: 3.5 meters

Material: 304# stainless steel

Water trough stand: one set



4. Belt haul off unit: one set

Control power: 0.75kw

Control style: frequency conversion



5. Cutting machine: one set

Hydraulic control style

Two blade cutting to ensure the shape
