Basic Info.

Model NO. KR165C Torque 165 Kn.M Max. Diameter 1500mm Max. Drilling Depth 56 M Max. Crowd Pressure 155 Kn Max. Crowd Pull 160 Kn Main Winch Line Pull 160 Kn Operating Height 19152mm Operating Width 4100mm Transport Package Bulk Pack Specification 49 t Trademark tysim Origin Jiangsu, China HS Code 8431499900 Production Capacity 30pieces/Month

Product Description

Technical Specification

Type	KR165C
Torque	165 KN.m
Max. diameter	1500 mm
Max. drilling depth	46 m
Speed of rotation	7~28 rpm
Max. crowd pressure	155 kN
Max. crowd pull	160 kN
Main winch line pull	160 kN
Main winch line speed	80m/min
Auxiliary winch line pull	60 kN
Auxiliary winch line speed	70m/min
Stroke(crowd system)	4200mm
Mast inclination(lateral)	±3°
Mast inclination(forward)	5°
Max. operating pressure	35 MPa
Pilot pressure	4 MPa
Track shoe width	700 mm
Operating height	19152 mm
Operating width	4100mm
Transport height	3321 mm
Transport width	3100 mm
Overall weight	49 t

Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.

FAQ

Q1: What is the Warranty of the Rotary Drilling Rig?

The warranty period for new machine is half a year or 1000 working hours, whichever comes first will be applied.

Please contact with us for detailed Warranty Regulation.

Q2: What's your service ?

We can offer professional technical support and good after-sale service to you.

Modification methods will be different according to different models and configurations of your owned excavators.

Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.

Before modifying, you need to confirm technical specification.
