1. Main ParametersMax. Drilling Depth600mDiameter of drill pipeΦ42,Φ50,Φ60,Φ76Angle of vertical spindle90°~65°Drilling capabilityΦ75mm drill diameterMax. Depth 600mΦ108mm drill diameterMax. Depth 500mΦ127mm drill diameterMax. Depth 400mΦ159mm drill diameterMax. Depth 300mΦ219mm drill diameterMax. Depth 210mΦ273mm drill diameterMax. Depth 150mΦ500mm drill diameterMax. Depth 80m2. Vertical SpindleRotation speedForward 10 grades30-1050r/minReverse 2 grades29-137r/minSpindle stroke560mmSpindle bore96mmHoisting capability6000kgMax. Torque3800N.m3. Main hoistLifting speed of single wire0.5-1.9m/sDiameter of wire rope12.5mmCarry capacity of single wire4000kgDiameter of winding drum300mmVolume of winding drum50mLifting capability of single wire3000kg4.Auxiliary Hoist Winding drum140mmDiameter of steel wire rope6mmVolume of winding drum450m5. Mud pump(as per your choice)Horizontal triplex mud pumpBW-200IIDisplacement200L/minWorking pressure50kg/cm² @ 5MPaDiameter of water inlet hose65mmDiameter of water outlet hose38mm6.Power supply(choose one between the following two)Diesel engineModel 4100,38kw(50PS)Electrical motorY180M-4B35,22kw7. Weight and Dimension of main drilling rigWeight2880kgDimension3700×1850×3200mm8.Six-wheel Trailer Walking speed25Km/hrFrame carrying capacity4 tonsSteering wheel 600-140.75 tonsBearing wheel 650-150.9 tonsMinimum turing angle6.8m9. Oil PumpCBN-F32Working pressure20MpaDisplacement32L/min
How to choose a suitable machine?
1. What will you do using drilling rig?
---For water project, core sample, soil test, mineral prospect or others?
2. The depth you need?
---For water well, generally, 30-200m. For core sample, 30-600m, even more.
3. Any requirements to hole diameter?
---Within a certain range, the smaller diameter, the deeper depth. Mathematically, we call it inversely proportional.
4. Working land condition?
A. soil, sand, weathered land, etc. soft stratum.
B. soil, sand, soft and hard rock stratum, mixed one.
C. Mainly hard rock, like granite.
Based on the above information, experienced engineers will help you recommend suitable machine. If you have special demands, please tell us in advance.

Defy Service:
1.Professional technical support pre-sale, sale and after-sale .
2.Your problems can get feedback in 8 hours and be solved in 24 hours.
3.Machine can be customized as per your requirement.
4.One year quality warranty.
5.Training: operation manual and DVD operation video, overseas installation is also available.
6.Spare parts are available in our factory at cost price for former customers.
