High Cost Performance Pile Hole Rotary Drilling Machine
Ruian Shengxiang Packaging Machinery Co., Ltd.Base Info
Description
LQ-25 crawler mounted locking rotary drilling rig technical figuresRig model LQ-25 Max. hole diameter 1500mm Max. drilling depth 25m Max. output torque 120-160 KN.M Drilling hole speed 6-35 rpm Max.add pressureof pressurized cylinder 80KN Max.lifting capacity of pressurized cylinder 120KN Max. lifting capacity of main hoist 150KN Max. lifting speed of main hoist 45m/min Max. lifting capacity of vice hoist 30KN Max. lifting speed of vice hoist 60m/min Max. stroke of pressurized cylinder 2500mm The mast tilt angle (left & right) ±4° The mast forward angle 4° Max. working pressure 28 Mpa Pilot pressure 4 Mpa Max. travel speed 5 km/h Height (working condition) 12800mm Width (working condition) 2600-2800mm Height (transportation condition) 3350mm Width (transportation condition) 2600-2800mm Length (transportation condition) 10800mm Total weight 24 T Diesel engine brand Cummins Type Water cooled, turbo Rated power 150 KW Max. torque 425N.M-735N.M
