• Model NO.：GCG-HT
• Filling Range：10-100g
• Material：Stainless Steel
• Warranty：1 Year
• Air Pressure：0.4-0.6MPa
• Power Supply：110,220V 50,60Hz
• Feature：High Efficiency
• Capacity：30-50PCS,Min
• Filling Accuracy：±0.5%
• Transport Package：Wooden Packing
• Trademark：MIJIAGAO
• Origin：Shanghai
• HS Code：8438600000
• Production Capacity：500

Basic Info.

Model NO. GCG-HT Filling Range 10-100g Material Stainless Steel Warranty 1 Year Air Pressure 0.4-0.6MPa Power Supply 110/220V 50/60Hz Feature High Efficiency Capacity 30-50PCS/Min Filling Accuracy ±0.5% Transport Package Wooden Packing Trademark MIJIAGAO Origin Shanghai HS Code 8438600000 Production Capacity 500

Product Description

Specifications:


The Hopper Topper transfer pumps convey smooth, liquid or lumpy batters directly from the mixing vessel, bucket and other containers to fill the hopper of your depositing systems and food processing machines. The photo sensor ensures to maintain the desired level in the hopper and takes care of automatic and continuous refill.


Characteristics:



• Easy on your product - maintains product integrity
• Fill hoppers direct from the bowl, tote or container
• Quickly pumps everything from smooth to chunky to thick
• Easy on your product - maintains product integrity
• Stainless steel construction allows for the system to be cleaned quickly and in dish washers



PART	DESCRIPTION
Pump Type	Pneumatic diaphragm type run by Compressor
Material contact	SS316
Material Non Contact	SS304
Document include	Manual book
Wheel base	Yes
Air Pressure	0.5-0.6 Mpa
Power	10W
Capacity	20L/min
Voltage	110/220V 50-60Hz
Size	87*89*143 cm
Weight	68kg
