4cavities Full-Automatic Pet Blow Moulding Machine
Qingdao Powerful Machinery Co., Ltd.Base Info
Description
Overview
Product DescriptionCONTAINERTheoretical output 3000 4000 6000 8000 Max.container volume 2L 2L 0.7L 0.7L Max.neck diameter 38mm 38mm 38mm 38mm Max.container diameter 105mm 105mm 70mm 70mm Max.container height 335mm 335mm 250mm 250mm Max.perform height 150mm 150mm 130mm 130mm Number of cavity 3 4 6 8 ELECTRICAL SYSTEM Motor power 3KW 3KW 3KW 3KW Heating power 30KW 33KW 35KW 45KW Actual total power 33KW 36KW 38KW 48KW AIR SYSTEM Operataiting low pressure 0.7Mpa 0.7Mpa 0.8-1.0Mpa 0.8-1.0Mpa Low pressure consuming 0.6-0.8m3/min 0.6-0.9m3/min 0.7-0.9m3/min 0.7-1.0m3/min Blowing pressure 3.5Mpa 3.5Mpa 3.5Mpa 3.5Mpa High pressure consuming 2-3m3/min 3-4m3/min 4-5m3/min 5-6m3/min CHILLER WHATER Operating pressure 0.3-0.5Mpa 0.3-0.5Mpa 0.3-0.5Mpa 0.3-0.5Mpa Temperature -10°C~55°C -10°C~55°C -10°C~55°C -10°C~55°C Flow rater 40L/min 40L/min 50L/min 70L/min MACHINE Machine dimension 3.5x2x2.2m 4x2x2.2m 4.9x2.15x2.2m 5.5x2.2x2.2m Machine weight 4200Kg 4800Kg 5000Kg 5800Kg
About Sunswell
