Items
Unit
Parameters
Engine
Make

Shangchai
Model

D6114ZG
Rated power
kW/ rpm
140/2300
Push/pull force
Type

Dual-motor chain type
Max. pull/push force
kN
280/280
Power head rotary speed
m/min
0~20
Slewing
Type

Motor + reducer gear drive
Max. torque of power head
N.m
10000
Power head rotary speed
r/min
0~120
Diameter
mm
φ73
Length (single)
m
3
Adjustment angle
°
10~23
Travel drive
Type

Self-propelled rubber crawler
Travel speed
km/h
2
Flow
L/min
250
Dimension
mm
7100×2260×2450
Weight
t
12.5
