Conical twin-crew extruder technical specification for HDPE Plast-Steel Profile Extrusion LineModelScrew Diameter(mm)Main Moter(kw)Output Capacity(kg/h)GSZ-4545/10015/18.560/80GSZ-5151/10518.5/2280/110GSZ-5555/11022/30120/150GSZ-6565/13237/45280/350GSZ-8080/15655/77380/450GSZ-80A80/17375500/650GSZ-9292/188110/132700/850GSZ-9595/196132/1601000 Downstream line technical specificationModel                   Max.product width(mm)       Total power(kw)    Water Cooling(m³/h)GYF110                  110                                          16                        4GYF240                   240                                        21-32                    7GYF300                   300                                        21-32                    7GYF400                   400                                        21-32                    7

Special configurationof HDPE Plast-Steel Profile Extrusion Line

1. GearBox
High efficiency single screw extruder , high output.

2.Feeding mechanism
Parallel twin-screw feeder, suitable for the feeding of powder and mixture .

3.Haul-off
New-designed haul-off structure , strengthen the design of torque .

4.No-dust Cutter
High precision cutting, no dust and low noise.
