Horizontal Directional Drill (HDD) Small Drilling Rig for Sale

Wenzhou Dongyin Machinery Manufacturing Co., Ltd.

Base Info

Description

Thrusting/Pulling SystemSpeed I: 6m/minSpeed II: 12m/minSpeed III: 24m/minThrusting Stroke3500MMGuide Hole Dia.130MMDrilling Angle8/20°Hydraulic System Pressure20MPaTravelling Speed2-2.6km/hMud Pump320L/minDimension6.5x2.25x2.4mWeight10,000kgRecommended Drill Pipeφ73x3000mmDrill Pipe Auto-loading Container OptionalClosed Driving Cabinet with ConditionerOptionalHydraullic AnchorOptionalNote: HDD drilling machine in different capcity available, please freely contact for details

II. Machine Photo and Working Site
