Machine model
Main data
LSJ-65/30
LSJ-90/30
LSJ-120/30
Extruder model
SJ-65/30
SJ-90/30
SJ-120/30
T-die head with
750mm
950mm
1350mm
Three roller calendars
diameter 360mm
diameter 400mm
diameter 450mm
Sheet width
400mm-600mm
600mm-800mm
800-1200mm
Sheet thickness
0.8-3mm
0.8-3mm
0.8-3mm
Sheet Density
0.4-0.7g/cm3
0.4-0.7g/cm3
0.4-0.7g/cm3
Main electrical parts
Siemens PLC controlled, ABB inverter, Omron thermocontroller, Schneider contactor
Installed power
110kw
150kw
180kw
Dimension
22m*2.5*2.7m
25m*2.8m*2.8m
28m*3m*3m

PART 3 Production flows:
Vacuum feeding machine>single screw extruder>hydraulic exchanger>T-die head>three roller calendars>thermoforming machine>cooling frame and edge cutting units>2 rubber rollers haul off machine>cutter-guillotine or twin position winder>material conveying able>stacker
 PART 4 PAYMENT, DELIVERY AND AFTER SALE SERVICESPayment terms40% for prepayment by T/T, 60% for balanced payment by T/T, or L/C can be acceptable  Delivery time 70 days after receipt of prepayment  Packing method Wooden cases/pallets with stretching films  Guaranteed time 18 months for mechanical parts, 12 months for electrical parts After sale service Send 1-2 engineers to customers' factory to help them install, test the machine, and train their workers. This is chargeable  Contact Ms Lilly Zhou (mob: 0086-15266238607)
