Machine Name

plastic roofing    production line

Warranty

18 months for mechanical parts, and 12 months for electrical parts

Total Power

180KW

Max. Output

350-400kg/h

Extruder Model

SJSZ80/156 conical twin screw extruder

Sheet width

720,880,1050mm

Sheet thickness

0.8-3mm

sheet layer

two laer, surface  layer PMMA or ASA,

Line Speed

0.5-4.5m/min

sheet application

roofing

Raw Material

PVC powder and PMMA or ASA and other addivity

Worker Requirement

2-3wokers a shift

Dimension

22m*4.5m*2.7m

Weight

13Tons

Voltage

Extruder model

SJSZ80/156 + SJ50/30

Capacity

350kg/h+50kg/h

Sheet specifications

Width: 720/880/1050mm

Wave pitch:160mm

Wave length:220mm

Wave height:30mm

Thickness:0.8-3mm

Emboss rollers

1400mm*Φ300mm

T-die head

JC-Times brand

Corrugation forming machine max haul off power

20KN

Haul off speed

0.3-5m/min

Cutting machine

Pneumatic saw cutting

Stacker

6m

Ridge tiles forming machine

With end cover, slope ridge for step roof, T ridge for step roof, top ridge for step roof

Other accessory machines

High speed mixer, plastic crusher, plastic pulverizer etc

PART 3: Advantages and applications of the PVC+PMMA/ASA roofing sheet

compared with other ordinary plastic tiles, this kind of composite glazed tiles have more beautiful appearance, better quality, strong durability, and some special features: such as fire retardant, impact capacity, anti-corrossion, anti-freeze, waterpfoof, weather resistance and color retention etc,

The glazed roofing tiles are wised in the garden-style factory, tourist scenic spots, pavillions, hotels, family building etc.

Synthetic resin tile, is the use of high-tech chemistry and chemical technology developed by new building materials, light weight, high strength, many fine features waterproof, corrosion retardant, noise insulation, etc., generally applicable to zone flat to pitched, farmers market, shopping malls, residential quarters, the new rural construction of luxury villas residents, awning, sunshadesantique buildings, garden-style factory, tourist scenic spots, pavillions, hotels, family building etc.
