• Model NO.：SB-10
• Condition：New
• Customized：Customized
• Place of Origin：Hubei, China (Mainland)
• Model Number：Sb-10
• Production Capacity：900-1200kg,H, 1000pieces,Year
• Power(W)：15 HP Diesel Engine
• Weight：230kg
• Certification：TUV
• After-Sales Service Provided：No Overseas Service
• Item：Diesel Rice Mill
• Output：900-1200kg,H
• Color：as Required
• Transport Package：Standard Export Package
• Specification：According to actual situation.
• Trademark：ACME
• Origin：Hubei

Basic Info.

Model NO. SB-10 Condition New Customized Customized Place of Origin Hubei, China (Mainland) Model Number Sb-10 Production Capacity 900-1200kg/H, 1000pieces/Year Power(W) 15 HP Diesel Engine Weight 230kg Certification TUV After-Sales Service Provided No Overseas Service Item Diesel Rice Mill Output 900-1200kg/H Color as Required Transport Package Standard Export Package Specification According to actual situation. Trademark ACME Origin Hubei

Product Description

Detailed Images:





Product Description:

SB10 rice mill is a comprehensive equipment for paddy processing. paddy first goes into machine
through vibrating sieve and magnet device,and then passes rubber-roller for bulling,after air blowing and air jetting to the milling room ,the paddy finishes the process
of busking and milling in succession.then busk,chaff,runtish,paddy,and white rice are pushed out of
 machine respectively,this machine adopts all the advantage of other types,and has comprehensive
layout,rational design,compact structure and little noise in operation. it is easy to operate whit less
power consumption and high productive.the model can product white rice with rice with high purity
 above national standard 1,and with less chaff containing and less broken.so it is indeed rice mill of
a new generation.

Specification:

1.Rice huller
  Rubber roller,Ø222×101.6mm(diameter×length)
  R.P.M of fast roller 1200(rpm)
  R.P.M of slow roller 830(rpm)
  R.P.M of hulk blower 1681(rpm)
2.Rice polisher
  Iron cylinder,Ø86×278mm (outer diameter of protrudes×length)
  Screw conreyor,Ø80×110mm(outer diameter×length)
  Hexagonal screen,Ø97×266mm
  Mesh of hexagonal screen,0.95×15mm
  R.P.M of main shaft of rice polisher 900(rpm)
  R.P.M of high pressure blower 3400(rpm)
 Techincal Parameters

Output	Power	Weight	Overall dimension
800-1000kg/h	15 hp diesel engine	230kg	760×730 × 1735mm

Certifications:
