Unity machine parameter Drilling depth30-200Drilling diameter(mm)300-75mmDrilling Angel(°)90-75Spindle rotating speed(r/min)64,128,287,557Spindle stroke(mm)450Main hoisting capacity(single line)(Kg)1600Main hoisting line capacity(m)35hoisting speed(r/s)17,35,75,151Wireline diameter(mm)12.5Mast height(mm)7000Mast effective height(mm)6500Kelly/active pipe(mm)59*53Drill rod(mm)42,50,60Drill rig weight(kg)1150Power UnitModel :ZS1115 desiel engineRated power: 14.7kw/2200rpmBW-160 mud pumpRated flow(L/min) 160Rated pressure(Mpa) 1.3Driving power(kw) 5.15main machine weight(kg) 190Dimension(mm) 1110*725*965Chassis                                                       Model7YP-1475D1Drive ModeRear-wheel drivePower UnitModel     ZS1115E2 emission standard-GB18322-2002,GB19756-2005) Rated power(KW)  16.2 Rotating speed(r/min)  2200
