2019 Newest Design Semi Automatic 5L Bottle Blow Moulding Equipment
Hangzhou Santiway International Co., Ltd.Base Info
Description
RM-5L-AMolding Clamping force kg 25000 Clamping stroke mm 220 Stretching stroke mm 400 Bottle Stroke mm / Cavity Spacing mm / Number of Cavity Cavities 1 Carriage Unit pcs 72 Theoretical Output bph 500 Electrical System Total Power kw 17 Heating Power kw 16 Number of Lamp Layers Layers 19 Air System Operating Pressure kg/cm² 7 Low Pressure Air Consumption Ltr/min 600 Blowing Pressure kg/cm² 25 High Pressure Air Consumption Ltr/min 1200 Chiller Operating Pressure kg/cm² 2-4 Temperature Range ºC 10-12 Consumption kcal/hr 2000 Flow Rate Ltr/min 30 Machine Blower Dimensions mm(L*W*H) 1850*650*1850 Blower Weight kg 1100
