• Model NO.：GJB
• Name：Ce Certificate 5000L Cream Milk Homogenizer with S
• Material：Stainless Steel 304 ,316
• Capacity：500L,H--10000L,H
• Pressure Details：250 Bar to 700bar
• Homogenizer Certificate：Ce
• Appications：Milk , Juice, Beverage, Butter, Honey, Cream
• High Pressure Homogenizer：Customized Electricity Motor
• Motor：Siemens ,ABB,China Brand
• Voltage Hz Phase：Make It to Your Order .
• Delivery：10 Days
• MOQ：1 Set
• Voltage：Make It to Your Order .
• Stage：2stage
• Packing：Wooden Box
• Spare Parts：Available
• Transport Package：Standard Wooden Box
• Specification：CE
• Trademark：KAIQUAN
• Origin：Shanghai, China
• HS Code：8479820090
• Production Capacity：100 Units , Month

Basic Info.

Model NO. GJB Name Ce Certificate 5000L Cream Milk Homogenizer with S Material Stainless Steel 304 /316 Capacity 500L/H--10000L/H Pressure Details 250 Bar to 700bar Homogenizer Certificate Ce Appications Milk , Juice, Beverage, Butter, Honey, Cream High Pressure Homogenizer Customized Electricity Motor Motor Siemens /ABB/China Brand Voltage Hz Phase Make It to Your Order . Delivery 10 Days MOQ 1 Set Voltage Make It to Your Order . Stage 2stage Packing Wooden Box Spare Parts Available Transport Package Standard Wooden Box Specification CE Trademark KAIQUAN Origin Shanghai, China HS Code 8479820090 Production Capacity 100 Units / Month

Product Description

Homogeniser For Milk Homogenzator Price Homogeniser Cream Homogenzator Milk Homogeniser
CE Certificate 5000L Cream Milk Homogenizer With Spare Parts

High pressure homogenization is a standard industrial process for dairy products, to improve their stability and shelf life
1000 Yogurt Homogenizer For Dairy

Model No. Technical parameter	KQ0.5-25	KQ1-25	KQ1.5-25	KQ2-25	KQ2.5-25	GJB3000-25 KQ3-25	KQ5-25
Rated pressure(MPa)	25	25	25	25	25	25	25
Rated flow ( Liters/H )	500	1000	1500	2000	2500	3000	5000
Medium temperature(C)	≤85	≤85	≤85	≤85	≤85	≤85	≤85
Feeding pipe diameter(mm)	25	25	25	25	25	32	40
Discharge pipe diameter(mm)	15	15	20	20	20	20	25
Power of motor(Kw)	5.5	7.5	11	15	18.5	22	45
Volt and Electricity Flow	220V,60HZ,3PH	380V,50HZ	380V,50HZ	380V,50HZ	220V,60HZ,3PH	380V,50HZ	380V,50HZ
Outline dimension (m) Length * width * height	1.16×0.9×1.24	1.16×0.9×1.24	1.16×0.9×1.24	1.4×1.1×1.42	1.4×1.1×1.42	1.4×1.1×1.42	2.2×1.45×1.1
Weight(Tons)	0.4	0.5	1.25	1.25	1.25	1.25	1.7

series is the kind of equipment which can homogenize the liquid material and make it become high-pressure spray. The high pressure homogenizer pump reciprocates the pump position, high press the liquid, fully mixed and refined the material.
The high pressure homogenizer can use to homogenize the dairy product material in high pressure, refine the fat globule, prevent or decrease the stratifying of the liquid material; Make the product much more nicety, to prove the quality of the product.
The high pressure homogenizer pump also the important equipment of the powder manufacture. (Such as pharmaceutical industry, chemical industry, etc. )

CE Certificate 5000L Cream Milk Homogenizer With Spare Parts .
