2021chinaplas ABA PE Film Blowing Machine
Classic Hardware Co., LtdBase Info
Description
Model
Suitable material:HDPE LDPE LLDP
Film width:200-800mmm.
Film thickness:HD(0.009-0.15mm);LD(0.02-0.15mm).
Max extrusion output: HD(50KG);LD(80KG).
gear case:146x1;173x1,HANGZHOU Xiaoshan.
Inverter:15kwx1,18.5kwx1made in china
Low-voltage apparatus:.Made in china
Volotage380V,50HZ,3PHASE.
Screw diameter:45x1,50x1
Screw L/D length:1:30
Screw material: Sacm-645/38Crmoala
Cylinder material: Sacm-645/38Crmoala
Cylinder cooling:250W(6P).
Feed device cooling: water circulating.
Main motor:18.5KW(4)*1,15kwx1..Made in china
Average power consume:35kw.
Heating areas:4*2. 4zone*2
Drum loader: x2, Auto Loderx2
Die size: 60+80()..Taiwan style high speed die head.
Temperature control:3 zone temperature controller.
Air ring: Dual-lip air ring
Height of air ring:200mm.
Width of air ring: ø760mm.
Air blower:5.5KW,. Made in china.
Center steady stick1P.
Wind pipe: φ70×6pcs.
Electrical controller system:(1:1.0)+1.5KW.Twrbine Reducer(1:7.5)+1.5kw motor.
Take-up unit: 2.1m
knurling roll: φ124×900mm..Controlled by air
Pinch roller: φ165×900mm..
Roller width:900mm.
Effective width:800mm.
Height adjustable:700mm.
Take-up speed: 10-100m/min.
Take-up motor:1.5KW.
Type: surface friction type 1.5kw
Winder:1.1KW..Speed controlled by inverter.
Winding speed: 10-100m/min.
Effective motor and control system:NMRVN7.5KW,1:7.5 .Turbine reduce inverter
Winding roller: 2
