Model()
 PA-45/500   PA-55/700    PA-65/900  PA-75/1000Width of the film
()75-350mm   200-550mm  300-700mm 400-800mmThickness of the film()0.002-0.08mmThe max output()40kg/h   55kg/h   80kg/h  110kg/h
According to different width,thickness of film, die size and raw material characteristics to change
(,,)Raw material()PP/LDPEPower consumption()10kw/h   15kw/h  20kw/h  30kw/h Weight()2500kg   2800kg  3500kg  4200kg Overall dimension(L*W*H)m
(**)3.5*2.1*3.5  4.2*2.5*4.4.5*2.5*4.3  4.8*3*4.5Extruder unit()Diameter of screw
()Φ45   Φ55   Φ65  Φ75
38CrMoALA  wearproof Alloy steel,five years guarantee
(38CrMoALA,)L/D ratio of screw
()30:1Rotation speed of screw
()10-120r/mBarrel Fan
()Zone 3 barrels install over-temperature fan
(3)Gear box()146#  173#  200#  225#
Extruder special hard gear reducer,tooth grinding teeth hardened, internal and external oil circulation system
(,,)Main motor()11kw  15kw  30kw 37kw
100% Original three-phase variable frequency motor  Equipped with inverter control
(100%   )Die head unit()Die diameter
()   80mm  120mm   160mm  250mm
With 40Cr steel forging finishing, eight feed trough runner,Uniform flow channel,blown plasticizing effect
(40Cr,8,,)Cool unit()Air ring type
() PP Single outlet air ring(PP )Air ring material
()High quality Taiwan cast aluminum alloy air ring
()Bellow power
()1.5kw  4kw   2.2kw
Shanghai production of high-pressure mute fan
()Traction unit()Width of take up roller
()500mm  700mm   900mm   1000mm  Traction roller material
() silicone roll()
NBR roller()Take up motor
()1.5kw  2.2kw  3.0kw
Installation of RV series reducer variable frequency motor inverter control
(RV  ) Take up speed
()100m/minwater cooling system()Aluminum high precision water ring (   )
Economic water ring of iron sheet ()Lambdoidal board
()Stainless steel perforated plate()Gusset equipment
()Modular rack type    ()
Independent Split  ()Guide roller()Aluminum guide roller (HV300-HV700) surface treatment
( (HV300-HV700))Winding unit()Winding type
()Double station double layer central receiving machine()Drive type()Torque motor equipped RV reducerFilm expanding roller()Smoothing rollElectric control cabinetlow-voltage is Universal electrical appliances, Delixi Electric, Taiwan's Yangming Electric, Huibang temperature control table
 Computer control type7-inch touch screen + process control system
Automatic air supply device Service
1.Free installation and ajustment.(for consumers purchase more than $100000 only)
2.One year free after-sales service(No charge for changing parts) and mechanical parts lifetime warranty.
3.We will offer you the professional answers about the relating machines in 24 hours
