1.Main parameterDrilling depth200mMaximum borehole caliber400mmMinimum borehole caliber75mmDiameter of Drill pipe425060mmDrilling angle90°~75°2.Vertical Spindle Spindle rotating speed64128287557r/minSpindle stroke450mm3.Hoist Max. single line lifting capacity1600kgfReel lifting speed173575151m/s4. Mud pump TypeBW-160TypeHorizontal Single Cylinder with 2 purpose5. Power Diesel engine22HPElectric15KW6. Drilling tower TypeIntegrated on drilling rigControl systemHydraulic Please let us know the following questions,for better matching the suitable drilling rig model to your business,thanks:

1. What kind of projects you will work for,Water well,Borehole,Exploration coring,Foundation Piling or others?
2. The Max. depth of drilling you hope to achieve?
3. The Min. and Max. diameters you estimate?
4. Condition of the environment,Soft ground like soil,mud,Hard ground like rocks or Mixed the soft and hard layers?


Other models of XY-Series for your choice&Technical Specification of model XY-200F:Geological exploration & survey;
Mineral prospecting;
Water wells;
Blast hole;
Geothermal air-conditioner holes and so on.XY-130300mm~75mm130mXY-150400mm~75mm150mXY-180400mm~75mm180mXY-200400mm~75mm200mXY-200T400mm~75mm200mAdvanced Model with Integrative Foldable MastXY-200C400mm~75mm200mXY-600F500mm~75mm600m
