Horizontal Directional Drilling Machine for Pipe Crossing Project Ddw-3000
Wenzhou Keepon Machinery Import & Export Co., Ltd.Base Info
Description
power
Rated speed
Fuel tank capacity
HP
(rpm)
(L)
750
2100
600
Hydr.oil tank capacity
Rated pressure
System flow rate
(L)
Mpa
L/min
870
35
1500
Max. torque
Rotary speed
Carriage travel speed
Floating spindle distance
(kNm)
(r/min)
(m/min)
mm
100
0-92
37
100
Thrust force
Pull back force
Dia. Length on Drill rod
Free working
(T)
(T)
(mm)
Free working length
Diameter range
Gripping force(Single cylinder)
Max unscrew torque
(m)
(mm)
KN
KN.m
11
φ89~φ310
950
220
Capacity
T
5
(LxWxH)
(m)
17.7 x 3.1x 3.3
