| Mechanical parts: | Parameter: |
| Rang of pipe belling | Ø63-200 |
| Rang of pipe thickness | 2.0-11.9mm |
| QTY. of heating oven | 2 |
| QTY. of belling station | 1 |
| Length of belling pipe | 4-6m |
| Chilling water | 0.2 m3/h |
| Calibration(cooling) type | Water or Air cooling |
| Belling control | Automatic, manual |
| Heating control | Adjustable |
| Pipe tipping | Automatic |
| Pneumatic pressure | 0.6-0.8Mpa,adjustable |
| Hydraulic oil pump model | VPV1-70-20 |
| Rated pressure of hydraulic oil | 6.3Mpa, the working pressure is adjustable |
| Belling Socketing Tools material | 40Cr,rigidity HV800-900, chrome plate surface |
